Packaging & Delivery
Selling Units:Single item
Single package size: 80X90X10 cm
Single gross weight:100kg
Package Type:Hot sale High precise glue dispenser
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher, we will use pe film for packing or pack it according to customers special request.
Thank you for visiting us, Best customization service will provide to you.
| Aluminum alloy gluing robot(single component) | ||||||||
| Model | DJ331 | DJ331R | DJ431 | DJ431R | DJ4331R | DJ5331R | DJ641 | |
| Axis range | X | 300mm | 300mm | 400mm | 400mm | 400mm | 500mm | 600mm |
| Y-1 | 300mm | 300mm | 300mm | 300mm | 300mm | 300mm | 400mm | |
| Y-2 | 300mm | 300mm | ||||||
| Z | 100mm | 100mm | 100mm | 100mm | 100mm | 100mm | 100mm | |
| R | 360° | 360° | 360° | 360° | ||||
| Product dimension (mm) | L | 640 | 640 | 640 | 640 | 740 | 840 | 940 |
| W | 590 | 590 | 590 | 590 | 590 | 590 | 690 | |
| H | 800 | 800 | 800 | 800 | 800 | 800 | 800 | |
| Drive Mode | Grinding line trial+ Stepping+ synchronous belt | |||||||
| Motor power | 350W | |||||||
| Control system | Four-axis control system | |||||||
| Repeating Precise | ±0.04mm | |||||||
| Path edit | hand-held program controller | |||||||
| Output speed | 5-100g/5s | |||||||
| Glue supply | Pneumatic | |||||||
| Air presure | 0.5~0.8mpa | |||||||
| File storage | 999 programs | |||||||
| Hot-melt glue | Available | |||||||
| Expansibility | Multiple expansibility in various industry process | |||||||
| Program | point,line,arc,circle,irregular figure and supporting 4 axis action | |||||||
| Working Environment | Temperature 0-40℃, humidity 20-90% | |||||||
| Power | 220/110V 50Hz (Please specify) | |||||||
| Body weight(kg) | 35 | 35 | 45 | 45 | 55 | 60 | 65 | |
1 Q: Are you trading conpany or manufacturer?
A: We are manufacture.
2 Q: What is your terms of packing?
A: Generally, we pack our goods in hard brown box for small machine and plywood box for big machine.
3 Q: What is your terms of payment?
A: Payment≤10000 USD, 100% T/T in advance. Payment≥10000 USD, 50% T/T in advance, balance before shipment.
4 Q: What is your terms of delivery?
A: Sea shipping, air shipping
5 Q: How about your delivery time?
A: 7-25 days after receiving down payment. The specific time depends on the items and the quantity of your order.
6 Q: Can you produce according to the samples testing?
A: Yes, we can make testing by your sample or technical drawing.
7 Q: Do you test all your goods before delivery?
A: Yes, we test at least 5 times before shipping and running for 1 day or more.
8 Q: Warranty and after sales service
A: We provide 1 year warranty free for spare parts, Whole life technical support.
