Factory direct high-quality and high-efficiency automatic screwing machine three-axis lock screw machine
Packaging & Delivery
Selling Units:Single item
Single package size:59X58X72 cm
Single gross weight:80.000 kg
Package Type:wooden box
Lead Time :
Quantity(Sets) 1 - 5 6 - 10 >10
Est. Time(days) 10 15 To be negotiated
|
Parameter |
||||||
|
Model |
6331 High match |
|||||
|
Number of controlled axes |
Three-axis |
|||||
|
Effective travel |
X axis |
Y1 axis |
Y2 axis |
Z axis |
||
|
600mm |
300mm |
300mm |
100mm |
|||
|
Transmission mode |
Double-track timing belt |
|||||
|
Power source |
Closed loop motor |
|||||
|
Top speed |
X, Y axis 500mm / s, Z axis 300mm / s |
|||||
|
Repeat accuracy |
±0.05mm |
|||||
|
Maximum load |
X/Y/Z-5kg/5kg/3kg |
|||||
|
Control System |
X, Y axis 500mm / s, Z axis 300mm / s |
|||||
|
Power |
AC110-250V 50-60LZ 350W |
|||||
|
Size |
L |
W |
H |
|||
|
720mm |
685mm |
596.5mm |
||||
